KP-009 Cosmetic Tube Sealing Machine
This tube sealer is applicable to toothpaste, cosmetic, pharmaceutical, food, industry product and other soft tube sealing.
Extensional organization of the machine is made of aluminium alloy and stainless steel.
Description
1. Tube sealing machinery is suitable for toothpaste, cosmetics, medicines, food industrial supply etc.
2. With horizontal aluminum alloy structure, stainless steel package, environment friendly and sanitation.
3. With independent platform, vertical /horizontal adjustable worktable, worktable, easy operation stable performance ,high efficiency.
Features
1. Tube sealing machinery has two dimensional adjustment of work piece platform, it is easy to operate.
2. Tube sealing machinery adopts Taiwan cassette mechanism and circuit Lines, using famous brand of Ultrasonic parts.
3. Overload protection, phase separation protection, power-fail protection.
4. Large ultrasonic output power to ensure the sealing quality of various specifications of tube.
5. Tube sealing machinery can sealing soft tube also can printing date and cutting
Advantage
1. Tube sealing machinery is suitable for toothpaste, cosmetics, medicines, food industrial supply etc.
2. With horizontal aluminum alloy structure, stainless steel package, environment friendly and sanitation.
3. With independent platform, vertical /horizontal adjustable worktable, worktable, easy operation stable performance ,high efficiency.
Applications
The semi automatic ultrasonic tube sealing machine is widely used in pharmaceutical, cosmetic, food and chemical industries etc. Various products that can be filled by these tube filling machines such as cream, paste, liquid, adhesives, grease, sauce,& others.
Parameter Data
Model
|
KP-009
|
Name and model
|
AD-20 Semi-automatic tube sealing machine
|
Max filling speed
|
600-900 pcs/hour
|
Applicable tube diameter size
|
Φ10 ≤D≤Φ50mm
|
Applicable bottle height size
|
10≤H≤250 mm
|
Voltage
|
AC220V , single phrase, 50/60HZ
|
Power
|
1800W
|
Working pressure
|
0.6MP
|
Net weight
|
85Kgs
|
Machine size
|
850*500*730mm
|
Ultrasonic frequency
|
20khz
|
