KP-009 Cosmetic Tube Sealing Machine

This tube sealer is applicable to toothpaste, cosmetic, pharmaceutical, food, industry product and other soft tube sealing.

Extensional organization of the machine is made of aluminium alloy and stainless steel.

Description

1. Tube sealing machinery is suitable for toothpaste, cosmetics, medicines, food industrial supply etc.

2. With horizontal aluminum alloy structure, stainless steel package, environment friendly and sanitation.

3. With independent platform, vertical /horizontal adjustable worktable, worktable, easy operation stable performance ,high efficiency.

Features

1. Tube sealing machinery has two dimensional adjustment of work piece platform, it is easy to operate.

2. Tube sealing machinery adopts Taiwan cassette mechanism and circuit Lines, using famous brand of Ultrasonic parts.

3. Overload protection, phase separation protection, power-fail protection.

4. Large ultrasonic output power to ensure the sealing quality of various specifications of tube.

5. Tube sealing machinery can sealing soft tube also can printing date and cutting

Advantage

1. Tube sealing machinery is suitable for toothpaste, cosmetics, medicines, food industrial supply etc.

2. With horizontal aluminum alloy structure, stainless steel package, environment friendly and sanitation.

3. With independent platform, vertical /horizontal adjustable worktable, worktable, easy operation stable performance ,high efficiency.

Applications

The semi automatic ultrasonic tube sealing machine is widely used in pharmaceutical, cosmetic, food and chemical industries etc. Various products that can be filled by these tube filling machines such as cream, paste, liquid, adhesives, grease, sauce,& others.

Parameter Data

Model
KP-009
Name and model
AD-20  Semi-automatic tube sealing machine
Max filling speed
600-900 pcs/hour
Applicable tube diameter size
Φ10 ≤D≤Φ50mm
Applicable bottle height size
10≤H≤250 mm
Voltage
AC220V , single phrase, 50/60HZ
Power
1800W
Working pressure
0.6MP
Net weight
85Kgs
Machine size
850*500*730mm
Ultrasonic frequency
20khz
